Photometric
- Item code
- LP-STR313090
- Output
- 12,600 lm · 90 W
- Beam angle
- 36°
- Peak intensity
- 32,419 cd
- Centre lux at 2 m / 3 m
- 8,105 / 3,602 lx
- Beam width at 3 m
- 1.95 m
- BUG rating
- B4-U0-G0
- CRI
- >90
Calculated from rated lumens, power and beam angle for lighting design — not a laboratory measurement.
Loop
Loop Street Light series luminaire is the ideal solution that fulfils requirements of functional street lighting and residential areas, which working with outstanding heat dissipation and compacting system. Equipped with high-quality electrical components, long lifetime is assured. Tool-free design and disconnector device, enables easy, safe and minimal cost for maintenance. Efficient system also to reduce energy consumption and to create a more attractive urban living environment and visual comforts for public and residential areas. – With patented housing design and range of optics, Loop series luminaire is also available with SPD Optional 10/15/20KV & Photocell NEMA socket 3 pin & 7 pin.
Item Codes
| Item Code | Power | Lamp | Lumen | Dimensions |
|---|---|---|---|---|
| LP-STR313018 | 18W | LED | 2520lm | A621 X B287 X C118 mm |
| LP-STR313035 | 35W | LED | 4900lm | A621 X B287 X C118 mm |
| LP-STR313045 | 45W | LED | 6300lm | A621 X B287 X C118 mm |
| LP-STR313060 | 60W | LED | 8400lm | A621 X B287 X C118 mm |
| LP-STR313070 | 70W | LED | 9800lm | A621 X B287 X C118 mm |
| LP-STR313080 | 80W | LED | 11200lm | A738 X B289 X C118 mm |
| LP-STR313090 | 90W | LED | 12600lm | A738 X B289 X C118 mm |
| LP-STR3130100 | 100W | LED | 14000lm | A738 X B289 X C118 mm |
| LP-STR3130120 | 120W | LED | 16800lm | A738 X B289 X C118 mm |
| LP-STR3130150 | 150W | LED | 21000lm | A922 X B362 X C140 mm |
| LP-STR3130165 | 165W | LED | 23100lm | A922 X B362 X C140 mm |
| LP-STR3130185 | 185W | LED | 25900lm | A922 X B362 X C140 mm |
| LP-STR3130240 | 240W | LED | 33600lm | A922 X B362 X C140 mm |
