Photometric
- Item code
- LP-UWL503006
- Output
- 720 lm · 6 W
- Beam angle
- 36°
- Peak intensity
- 1,853 cd
- Centre lux at 2 m / 3 m
- 463 / 206 lx
- Beam width at 3 m
- 1.95 m
- BUG rating
- B1-U0-G0
- CRI
- >90
Calculated from rated lumens, power and beam angle for lighting design — not a laboratory measurement.
Line
Line Wall Washer is 24VDC IP67 protected and IK10 linear LED luminaire for indoor and outdoor in-ground installation. It featured Entirely made of stainless steel 316Ti (resistant to corrosion) for lamp housing, built-in aluminum heat sink, frameless design and 15mm thickness frosted tempered glass. Frameless design for two ends of linear luminaire enables Seamless splice installation of numerous fixtures possible. Available in standard length 500mm or 1000mm, or customized length. Suitable for installation into roads, garden and parking lots. It is Anti skid toughened safety glass (ESG)-withstands loads of up to 2500KG. Delivered with male / female IP68 connectors.
Item Codes
| Item Code | Power | Lamp | Lumen | Dimensions |
|---|---|---|---|---|
| LP-UWL503006 | 06W | LED | 720lm | A500 X B87 X C41 mm |
| LP-UWL503012 | 12W | LED | 1440lm | A1000 X B87 X C41 mm |
