Photometric
- Item code
- LP-UL653507
- Output
- 840 lm · 7 W
- Beam angle
- 38°
- Peak intensity
- 1,944 cd
- Centre lux at 2 m / 3 m
- 486 / 216 lx
- Beam width at 3 m
- 2.07 m
- BUG rating
- B1-U0-G0
- CRI
- >90
Calculated from rated lumens, power and beam angle for lighting design — not a laboratory measurement.
Floor Lights
Opo
Black
Compact drive-over and walk over inground Opo LED luminaire designed for illuminating building facades, green areas, parks and outdoor facilities. With the use of high-power LEDs, the in-ground light range provides high luminosity at a low power consumption.Adapting a double insulation method, all in-ground lights have an IP67 ranking featuring thick tempered glass. Designed to last in extremely harsh environments.
Item Codes
| Item Code | Power | Lamp | Lumen | Dimensions |
|---|---|---|---|---|
| LP-UL653507 | 07W | LED | 840lm | A100 X B140 mm |
Technical Specification
Construction
HousingBody in Aluminum Die-Casting, 304 grade Stainless steel cover in 4mm Thickness.
DiffuserTempered Clear/Frosted Glass in 8mm Thickness, Silicon Rubber Gasket, Recessed Plastic Box
Color AvailableBlack
ReflectorAluminium Reflector
Optical & Performance
Beam Angle15° / 25° / 38° / 45° / 60°
Lifespan>50,000 Hours (L90 B10)
Electrical
VoltageAC220~240V
LED DriverLight Plus, TriDonic, PHILIPS, OSRAM, MW
Protection & Environment
Working Temperature-20C° ~ 60C°
IP Rating67
IK10
