Photometric
- Item code
- LP-SL192408
- Output
- 960 lm · 8 W
- Beam angle
- 36°
- Peak intensity
- 2,470 cd
- Centre lux at 2 m / 3 m
- 618 / 274 lx
- Beam width at 3 m
- 1.95 m
- BUG rating
- B1-U0-G0
- CRI
- >90
Calculated from rated lumens, power and beam angle for lighting design — not a laboratory measurement.
Spot Lights
NARVI – I
White & Black
Narvi I recessed square tilting down light is made of constructed from durable die casting aluminum with high efficiency reflector , without any shadow, accurate angle, high lumen and PC clear diffuser and optical lens. Narvi I light fixture features a CREE COB LED module that maintains uniform intensity. It’s an excellent lighting choice for the living room, bedroom, hallway, kitchen, offices etc.
Item Codes
| Item Code | Power | Lamp | Lumen | Dimensions |
|---|---|---|---|---|
| LP-SL192406 | 06W | LED | 720lm | A84 X B70 X C74mm |
| LP-SL192408 | 08W | LED | 960lm | A84 X B70 X C74mm |
| LP-SL192410 | 10W | LED | 1200lm | A84 X B70 X C74mm |
| LP-SL192415 | 15W | LED | 1800lm | A84 X B70 X C74mm |
Technical Specification
Construction
HousingDie-Cast Aluminum
DiffuserClear Glass
Color AvailableWhite & Black
ReflectorAluminium Reflector
Optical & Performance
Lifespan>50,000 Hours (L90 B10)
UGR<19
Beam Angle15° / 24° / 36°
Electrical
VoltageAC220~240V
LED DriverLight Plus, TriDonic, PHILIPS, OSRAM, MW
Protection & Environment
Working Temperature-25°~+65°C
IP Rating65
