Decorative Poles
Lumen Tower
Black & Grey
A roadway fixture focused on visual comfort and uniformity. The flat glass and internal baffles reduce high-angle brightness, improving night-time visibility. Pre-wired terminal blocks and captive screws speed up installation.
Item Codes
| Item Code | Power | Lamp | Lumen | Dimensions |
|---|---|---|---|---|
| LP-STR318860 | 60W | LED | 4*1003lm | A1300 X B565 X C1880 mm |
| LP-STR318890 | 90W | LED | 6*1003lm | A1550 X B675 X C1780 mm |
| LP-STR3188180 | 180W | LED | 9*1262lm | A2130 X B790 X C1980 mm |
| LP-STR3188220 | 220W | LED | 11*1262lm | A2130 X B790 X C2215 mm |
Technical Specification
Construction
HousingDie Cast Aluminum
DiffuserOpal PC
Color AvailableBlack & Grey
Optical & Performance
Beam Angle120°
Lifespan> 50,000 Hours (L70 B10)
Electrical
VoltageAC220~240V
LED DriverLight Plus, TriDonic, PHILIPS, OSRAM, MW
Protection & Environment
Working Temperature-20C° ~ +65C°
IP Rating65
IK10
TMSeries WiringRohsRecycleProtectionPluginLM 80OutdoorLEDFlicker FreeFEnergy StarENECCRI 90CidetCEA
