Photometric
- Item code
- LP-553132
- Output
- 1,440 lm · 26 W
- Beam angle
- 36°
- Peak intensity
- 3,705 cd
- Centre lux at 2 m / 3 m
- 926 / 412 lx
- Beam width at 3 m
- 1.95 m
- UGR
- <19
- CRI
- >90
Calculated from rated lumens, power and beam angle for lighting design — not a laboratory measurement.
Wall Surface
Doomy
Black and Grey
White
Indoor and outdoor ceiling light fixture suitable for homes, shops, offices production sites.
Item Codes
| Item Code | Power | Lamp | Lumen | Dimensions |
|---|---|---|---|---|
| LP-553118 | 18W | LED | 840lm | A120 X B32 mm |
| LP-553132 | 26/36W | LED | 1440lm | A170 X B32 mm |
| LP-554218 | 2X18W | LED | 2400lm | A255 X B32 mm |
| LP-554226 | 2X26W | LED | 1440lm | A170 X B32 mm |
Technical Specification
Construction
HousingInjection moulded themo polycarbonate (PMMA) material reinforced with fibber glass.
DiffuserOpal injection moulded polycarbonate diffuser
Color AvailableWhite, Black and Grey
ReflectorHigh purity anodized aluminum reflector
Optical & Performance
Beam Angle15° / 24° / 36° / 45°
Electrical
LED DriverLight Plus, TriDonic, PHILIPS, OSRAM, MW
Protection & Environment
IP Rating44
Further Details
StandardsDesigned and Manufactured to comply with EN 60598
TMSeries WiringRohsRecycleProtectionPluginIndoorLM 80LEDFlicker FreeFEnergy StarENECCRI 90CidetCEA
