Photometric
- Item code
- LP-PL232030
- Output
- 3,600 lm · 30 W
- Beam angle
- 90°
- Peak intensity
- 1,776 cd
- Centre lux at 2 m / 3 m
- 444 / 197 lx
- Beam width at 3 m
- 6 m
- UGR
- <19
- CRI
- >90
Calculated from rated lumens, power and beam angle for lighting design — not a laboratory measurement.
Suspended & Pendant
Roundy
Black
Dark-Gray
White
This pendant offers another option for contemporary indoor lighting solutions. Surrounded by a cylindrical metalstructure, with durable white/silver/black powder coat finish, PMMA diffuser, oering a comfortable diffused light, High transmission opal diffuser, Suspension installation
Item Codes
| Item Code | Power | Lamp | Lumen | Dimensions |
|---|---|---|---|---|
| LP-PL232025 | 25W | LED | 3000lm | A360 X B90 mm |
| LP-PL232030 | 30W | LED | 3600lm | A480 X B90 mm |
| LP-PL232036 | 36W | LED | 4320lm | A600 X B90 mm |
| LP-PL232040 | 40W | LED | 4800lm | A600 X B90 mm |
Technical Specification
Construction
HousingMetal Powder Coated Finish
DiffuserPMMA
Color AvailableWhite, Dark-Gray, Black
ReflectorAluminium Reflector
Optical & Performance
Beam Angle90° / 120°
Lifespan>50,000 Hours (L90 B10)
Electrical
VoltageAC220~240V
LED DriverLight Plus, TriDonic, PHILIPS, OSRAM, MW
Protection & Environment
Working Temperature-30C°~ + 65C°
IP Rating54
IK08
